The method includes the steps of constructing at least one of a mechanical fixture design, a workcell design, and a controls design. The method also includes the steps of executing a virtual programmable logic control VPLC simulation with a VPLC verification simulator to verify at least one of the mechanical fixture design, the workcell design, and the controls design.

One advantage of the present invention is that a method of embedding tooling control data within a mechanical fixture design to enable programmable logic control verification simulation is provided for use in building a manufacturing line to manufacture a motor vehicle.

NAFEMS European Conference: Simulation-Based Optimisation

Another advantage of the present invention is that the method reduces the amount of time it takes to conduct virtual programmable logic control verification simulations. Yet another advantage of the present invention is that the method increases the accuracy of virtual programmable logic control verification simulations. Still another advantage of the present invention is that the method lowers the potential for loosing mechanical design assumptions related to control system design through a body shop fixture tooling design process, such as naming conventions, tooling sequence description, bill of materials for control and mechanical items, etc.

A further advantage of the present invention is that the method supports effective control logic system design simulation approach by automatically producing tooling visualization data that describes the allowable tooling behavior, that is used by a virtual programmable logic controller. Yet a further advantage of the present invention is that the method exports mechanical fixture data such that all the relationships are maintained between tooling items that move e.

Still a further advantage of the present invention is that the method exports fabrication information from a mechanical fixture design to support a floor build of tooling. Other features and advantages of the present invention will be readily appreciated, as the same becomes better understood, after reading the subsequent description taken in conjunction with the accompanying drawings. Referring to the drawings and in particular FIG.

In the present invention, an operator 12 uses the system 10 to perform programmable logic control verification simulation. The system 12 includes a computer 14 to send and receive information to and from a design engineering source 16 via an electronic link. The design engineering source 16 includes a product design system, work cell design system, manufacturing cell design system, mechanical fixture and tooling design system, controls design system, plant layout design system, and other manufacturing line related design systems to provide engineering data for standard components, tools, fixture models, and robots to interact with the fixture models.

These design systems have the ability to read and write in a neutral file format. It should be appreciated that the above-mentioned design systems use either a specific file format such as VLE or other neutral file formats such as XML that contain information organized in a manner that is recognized and readily useable. It should also be appreciated that the neutral file formats are conventional and known in the art. The computer 14 also sends and receives information to and from a manufacturing engineering source 18 via an electronic link.

The manufacturing engineering source 18 includes data on manufacturing engineering such as a tooling line. The manufacturing engineering source 18 also sends and receives information to and from a manufacturing line build source 20 via an electronic link. The manufacturing line build source 20 includes data for building the manufacturing line not shown for the manufacture of parts not shown for a motor vehicle not shown.

The computer 14 also sends and receives information from a programmable logic control verification simulator 22 via an electronic link to verify the PLC for the manufacturing line. The manufacturing line verification simulator 22 verifies stand-alone workcells, workcell to workcell interactions, and total manufacturing line operation. The manufacturing line build source 20 automatically generates the programmable logic controller PLC code, which is then used at physical tool build.

An example of automatically generating PLC code for building a physical tool is disclosed in U. It should be appreciated that the computer 12 , electronic links, and sources are conventional and known in the art. Referring to FIGS. In general, the method embeds tooling control data within a mechanical fixture design to enable programmable logic control verification simulation of the PLC code.

The method facilitates the automatic inclusion and embedding of control related data in three dimensional computer aided drafting CAD mechanical fixture design and exports and aligns mechanical, control, and visualization data to be readily usable by the virtual programmable logic control verification simulator 22 for control system design verification. It should be appreciated that the method is carried out on the computer 14 of the system 10 by the operator Referring to FIG. In block , the method receives a description of a purchasable component such as a clamp from a library in the design engineering source The design engineering source 16 may include product design, manufacturing cell design, mechanical fixture and tooling design, plant layout design, and other manufacturing line related design data.

The product design information may be a single part or a plurality of parts to be assembled in a manufacturing line. The manufacturing cell design information typically includes flexible automation, for example robots, material handling, etc. The fixture and tooling design information typically includes hard tooling such as a clamp. The plant layout design information typically includes location of the manufacturing line, for example location of columns, aisles, etc. The other manufacturing line design information typically includes intersection points of other manufacturing lines where two manufacturing lines merge , location of control panels, remote valving stations, energy cabinets, and other items that take up space that potentially could interfere with tool movements and operator interactions.

In block , the method updates a library in the design engineering source 16 to adhere to industry standards. After block or block , the method advances to block and receives standard library elements from the design engineering source The standard library elements include a description of geometry, description of allowed behavior, fabrication information, control attributes, and kinematics. After block , the method advances to either block or In block , the method receives information of a mechanical fixture design from the design engineering source The mechanical fixture design includes mechanical sequence operations, predecessor relationships, motion files, and tessellated geometry.

The method advances to block and exports the information of the mechanical fixture design. The method advances to diamond and determines whether the mechanical fixture design is good or acceptable. For example, the operator 12 determines whether the clamp is of the correct size and shape. If the mechanical fixture design is good, the method advances to diamond to be described.

In diamond , if the mechanical fixture design is not good or correct, the method returns to block , previously described, to adjust the description of the mechanical fixture design by the fixture design system in the design engineering source The method then advances to block previously described. It should be appreciated that the information is imported and exported from the systems within the design engineering source In diamond , the method determines whether workcell components are required.

For example, the operator 12 determines whether a robot is needed to interact with the workpiece. If workcell components are required, the method advances to block and imports the data of the mechanical fixture design for block In block , the method receives information of the mechanical fixture design and selects the workcell design from the design engineering source The workcell design includes mechanical sequence operations, predecessor relationships, motion files, tessellated geometry, and sensors.

The method advances to block and exports the information of the workcell design. The method then advances to diamond and determines whether the workcell design is good or acceptable. For example, the operator 12 determines whether there is interference between a clamp moving and the location of a column of the manufacturing plant. If the workcell design is good, the method advances to block to be described. In diamond , if the workcell design is not good or correct, the method returns to block and block , previously described, to adjust the description of the workcell design by the workcell design system in the design engineering source In block , the method selects a controls design from the design engineering source For example, the operator selects the controls to be used for the manufacturing line.

After block , the method advances to block and exports the information of the controls design. The mixer has a conversion gain of 18 dB and an input referred third-order intermodulation intercept point of 16 dBm. The combination draws 5. Power consumption has become one of the main concerns in embedded system design. Currently, design platforms are composed of generic and specific hardware devices and general-purpose processors running the application software. SW functionality has a mayor impact on the total system power consumption.
